The iTEMP TMT82 is a highly reliable, accurate and long-term stable temperature transmitter for industrial processes requiring high availability. The versatile 2-channel device converts universal sensor inputs such as thermocouples or RTD into stable, scalable 4 to 20 mA output signals and HART® communication. With its built-in smart sensor monitoring capability and diagnostic status information according to NAMUR NE 107, the SIL 2, SC3 certified transmitter increases process safety and uptime.
| Measuring principle: | Head transmitter | |
| Input: | 2 x RTD, TC, Ohm, mV | |
| Output: | Head transmitter | |
| Auxiliary power supply: | 11…42 V DC (head transmitter) / 12…42 V DC (Din rail device) / 11/12…30 V DC (Ex ia) | |
| Communication: | HART-protocol | |
| Installation: | Terminal head form B, DIN-Rail housing or field mount housing | |
| Accuracy: | (Pt100, -50…200 °C) <= 0,1 K / (Pt100, -58…392 °F) <= 0,18 °F | |
| Galvanic isolation: | yes | |
| Certification: | ATEX II1G Ex ia IIC T4/T5/T6 ATEX II3G Ex ic IIC T6 ATEX II2D Ex tb IIIC Db ATEX II3D Ex tc IIIC Dc ATEX II3G Ex nA IIC T6 ATEX II1G Ex ia IIC T6, II3D ATEX II3G Ex nA IIC T6, II3D ATEX II2G Ex d T6, II2D Ex tb IIIC CSA C/US General Purpose CSA IS, NI I / 1+2/A-D CSA XP, NI, DIP I, II, III/1+2/A-G FM IS,NI I / 1+2/A-D FM XP, NI, DIP I, II, III/1+2/A-G EAC Ex ia IIC T6 Ga EAC Ex d IIC T6 Gb EAC Ex ia IIC T6, II3D IECEx Ex ia IIC T4/T5/T6 IECEx Ex tb IIIC Db IECEx Ex nA II T4/T5/T6 IECEx Ex d T6 Gb, Ex tb IIIC Db INMETRO Ex ia [ia Ga] IIC T6 Gb INMETRO Ex d T6 Gb, Ex tb IIIC Db NEPSI Ex ia IIC T6 Ga NEPSI Ex d IIC T6 Gb NEPSI Ex nA IIC T6 Gc TIIS Ex ia IIC T6 TIIS Ex nA II T6 UK II1G Ex ia IIC T6 Ga UK II2D Ex tb IIIC Db UK II3D Ex tc IIIC Dc UK II1G Ex ia IIC T6 Ga, II3D Ex ia IIIC Dc UK II3G Ex nA IIC Gc, II3D Ex tc IIIC Dc UK II2G Ex db IIC T6 Gb, II2D Ex tb IIIC Db ATEX IECEx II1G Ex ia IIC T6 Ga FM+CSA IS, NI I/1+2/A-D |
