DW Wall Scale

Rugged, reliable weighing solutions

for the meat processing industry

Are you looking for an overhead rail scale for weighing animal carcasses? Or a space-saving wall scale? METTLER TOLEDO has the right weighing system for your particular field of application.

Wall scale:

• Weighing capacity of 150 kg

• 1 x 3000 certifiable resolution

• Space-saving hinged plate

• Gallows with meat hook

• Brushed high-grade steel

Model	DW150
Plate size [mm]	600 x 400
Finish on visible surfaces	Stainless steel (1.4301/AISI 304)
Finish hinged plate support/internal frame	Hot galvanized
Type of protection	IP67
Type of connection	Analog / IDNet
Connection cable [m]	2.5
Maximum capacity [kg]	150
Minimum capacity [kg]	1
Taring range (by subtraction)	0 … maximum capacity
Preload range	1
Zero setting range [kg]	3
Preload range [kg]	27
Certification data to OIML Class III	e1/Max1 [g/kg] 50 / 150
Temperature range [°C]	-10…+40
Max. static safe load (central)	250 kg
Max. static safe load (side)	160 kg
Cornerload (1/3 max. capacity)	80 kg
Meat hook	120 kg
Repeatability s [kg]	0.01
Typical linearity [kg]	0.015
