Detect a Wide Range of Contaminants
Beyond metal, the X16 can detect glass, stone, bone and many low-density materials.
Enhance Product Quality
Go beyond contamination detection, to perform a variety of product integrity checks to improve product safety and quality.
Increase Productivity
An intuitive interface paired with a front-opening design provides easy access for cleaning and maintenance, increasing uptime and productivity
Material No.: 30541252000
| IP Rating | IP65, IP66, IP69 |
| Compatible Software | ProdX |
| Connectivity | Ethernet, OPC UA, USB |
| Inspection Solution | X-ray Inspection |
| Max Product Width | 380 mm |
| HMI | 15.6″ Touchscreen |
| Packaging Type | Cardboard, Cartons, Metalized Film, Plastic, Trays |
| Cooling Method | Air Conditioner |
| Product Flow | Conveyor |
| X-ray Beams | Single vertical beam |
| X-ray Generator | 100 W, up to 84 kV, up to 3.3 mA Glass Tube 420 W, up to 84 kV, up to 5.0 mA Glass Tube |
| Inspection Application | Clip Detection, Completeness Check, Contamination Detection, Fill level Check, Integrity Check, Mass Control, Product-Trapped in Seal |
| Product Characteristic | Medium-Large Packages |
| Industry | Chemical, Food & Beverage, Pharma & Biotech |
| Max Product Height | 200 mm |
| Industry Segment | Bakery and Confectionery, Beer/Wine/Alcoholic Beverages, Bulk Chemicals, Cosmetics, Dairy, Fine & Specialty Chemicals, Food Additives, Meat/Poultry/Seafood, Nutraceuticals, Oils & Fats, Pet Food & Animal Feed, Pharma, Ready Meals, Snack Foods, Sugar/Starch/Yeast, Water & Non-Alcoholic Beverages |
| X-ray Detector | Single Energy, HiGain Technology |
| Max Product Weight | 25 kg |
| X-ray Emissions | < 1uSv/hr |
| Max Line Speed | 100 m/min |
| Max Throughput | 1000 ppm |
| Diode Size | 0.4 mm |
