Unrivaled Inspection Results
The X3750 offers optimum X-ray beam geometry, removing all inspection blind spots and resulting in unrivaled glass-in-glass inspection of jars.
Reaching Outstanding Detection Levels
Your brand reputation is maintained at all times, as our unique ContamPlusTM X-ray inspection algorithms optimize detection levels with each process.
Supporting Uptime
Adjustable full-length guide rails facilitate quick and easy product set-up and consistent product presentation to the X-ray system.
Material No.: 3054124800
| IP Rating | IP65, IP69 |
| Compatible Software | ProdX |
| Connectivity | Ethernet, OPC UA, USB |
| Inspection Solution | X-ray Inspection |
| Max Product Width | 130 mm |
| HMI | 15.6″ Touchscreen |
| Packaging Type | Bottle, Glass |
| Cooling Method | Air Conditioner & Radiator Pump |
| Product Flow | Conveyor |
| X-ray Beams | Single horizontal beam |
| X-ray Generator | 420 W, up to 84 kV, up to 5.0 mA Glass Tube |
| Inspection Application | Completeness Check, Contamination Detection, Fill level Check, Integrity Check, Mass Control, Product-Trapped in Seal |
| Product Characteristic | Tall Rigid Containers |
| Industry | Chemical, Food & Beverage, Pharma & Biotech |
| Max Product Height | 260 mm |
| Industry Segment | Bakery and Confectionery, Beer, Wine and Other Alcoholic Beverages, Bulk Chemicals, Cosmetics, Dairy, Fine and specialty chemicals, Food Additives, Meat & Poultry & Seafood, Nutraceuticals, Oils and Fats, Pet Food and Animal Feed, Pharma, Ready Meals, Snack Foods, Sugar Starch and Yeast, Water and other Non-Alcoholic Beverages |
| X-ray Detector | Single Energy, HiGain Technology |
| Max Product Weight | 5 kg |
| X-ray Emissions | < 1uSv/hr |
| Max Line Speed | 100 m/min |
| Max Throughput | 800 ppm |
| Diode Size | 0.8 mm |
