Detect Hard-to-Find Contaminants
Capable of detecting hard-to-find contaminants in a variety of applications. Offering clarity and precision in complex areas of product inspection.
Enhance Product Quality
Achieves outstanding product quality using advanced levels of foreign body detection of low-density contaminants in overlapping products.
Increase Productivity
Clever design combined with an intuitive user interface to create user-friendly systems that increase uptime and boost productivity.
Material No.: 30541251900
| IP Rating | IP65, IP66, IP69 |
| Compatible Software | ProdX |
| Connectivity | Ethernet, OPC UA, USB |
| Inspection Solution | X-ray Inspection |
| Max Product Width | 380 mm |
| HMI | 15.6″ Touchscreen |
| Packaging Type | Cardboard, Cartons, Metalized Film, Plastic, Trays |
| Cooling Method | Air Conditioner |
| Product Flow | Conveyor |
| X-ray Beams | Single vertical beam |
| X-ray Generator | 100 W, up to 84 kV, up to 3.3 mA Beryllium Tube |
| Inspection Application | Clip Detection, Completeness Check, Contamination Detection, Fill level Check, Integrity Check, Mass Control, Product-Trapped in Seal |
| Product Characteristic | Small-Medium Packages |
| Industry | Chemical, Food & Beverage, Pharma & Biotech |
| Max Product Height | 200 mm |
| Industry Segment | Bakery and Confectionery, Beer/Wine/Alcoholic Beverages, Bulk Chemicals, Cosmetics, Dairy, Fine & Specialty Chemicals, Food Additives, Meat & Poultry & Seafood, Nutraceuticals, Oils and Fats, Pet Food and Animal Feed, Pharma, Ready Meals, Snack Foods, Sugar Starch and Yeast, Water & Non-Alcoholic Beverages |
| X-ray Detector | Dual Energy, HiGain+ DE Technology; Single Energy, HiGain+ Technology |
| Max Product Weight | 25 kg |
| X-ray Emissions | < 1 µSv/hr |
| Max Line Speed | 100 m/min |
| Max Throughput | 1000 ppm |
| Diode Size | 0.4 mm |
Like this product? Secure this item by sending your application today!
