Exceeding Detection Requirements
DXD+ detector technology can surpass market expectations for contamination detection and meet the most demanding customer specifications.
Improved Inspection with AMD
Powered by our AMD software with the latest advanced material discrimination algorithms, the DXD+ offers exemplary contamination detection.
User-friendly Features
Automated product set-up and intelligent software improve uptime, reduce costs and enhance detection sensitivity and minimize False Reject Rates.
Material No.: 30541251500
| IP Rating | IP65, IP69 |
| Compatible Software | ProdX |
| Connectivity | Ethernet, OPC UA, USB |
| Inspection Solution | X-ray Inspection |
| Max Product Width | 480 mm |
| HMI | 15.6″ Touchscreen |
| Packaging Type | Cardboard, Cartons, Metalized Film, Plastic, Trays |
| Cooling Method | Air Conditioner & Radiator Pump |
| Product Flow | Conveyor |
| X-ray Beams | Single vertical beam |
| X-ray Generator | 420 W, up to 84 kV, up to 5.0 mA Beryllium Tube |
| Inspection Application | Clip Detection, Completeness Check, Contamination Detection, Fill level Check, Integrity Check, Mass Control, Product-Trapped in Seal |
| Product Characteristic | Medium-Large Packages |
| Industry | Chemical, Food & Beverage, Pharma & Biotech |
| Max Product Height | 300 mm |
| Industry Segment | Bakery and Confectionery, Beer/Wine/Alcohol, Bulk Chemicals, Cosmetics, Dairy, Fine & Specialty Chemicals, Food Additives, Meat & Poultry & Seafood, Nutraceuticals, Oils & Fats, Pet Food & Animal Feed, Pharma, Ready Meals, Snack Foods, Sugar Starch & Yeast, Water & Non-Alcoholic Beverages |
| X-ray Detector | Dual Energy, DXD+ Technology |
| Max Product Weight | 25 kg |
| X-ray Emissions | < 1uSv/hr |
| Max Line Speed | 40 m/min |
| Max Throughput | 500 ppm |
| Diode Size | 0.4 mm |
